500mm (20″) Modular Cutter Suction Dredger
2004, IHC Beaver 5014C, BV class. Modular. Loa x B x D (m): 35 x 9.5 x 2.5. Dredgepump power: 745 kW. location: NE Europe Enquire
| General | |
| Built | 2004 |
| Class | BV, I ✠ Hull dredger coastal area • MOT |
| Dimensions | |
| Length oa, incl. ladder | 35.0 m |
| Length pontoons | 23.5 m |
| Beam | 9.5 m |
| Depth mld | 2.5 m |
| Draft | 1.50 m |
| Side pontoons, moulded | 23.5 x 3.0 x 2.5 m |
| Dredging particulars | |
| Dredging depth | 14 m |
| Suction pipe diameter | 500 mm |
| Discharge pipe diameter | 500 mm |
| Total dry weight approx. | 174 t |
| Machinery | |
| Dredge pump | IHC |
| Dredge pump engine | Caterpillar 3508 B-SCAC, 745 kW |
| Power pack (cutter, winches, spuds) | Caterpillar 3406C, 345 kW |
| Total installed power | 1,090 kW |
| Deck equipment | |
| Cutter | IHC, 170 kW, 1,455 mm, 30 rpm |
| Winches (ladder / swing) | 11 t pull, 20 m/min |
| Wire, anchors | 100 m x 24 mm, 730 kg each |
| Spuds | 2 x 18.6 x 0.6 m |
| Spud weight | 6.2 t each |
| Spud cylinders stroke | 2.10 m |
| Spud stroke | 3.15 m |
| Swing width | 30 m -39 m |
| Deck crane | 2.0 t at 3.5 m |
| Spud carrier | yes |
