Cutter Dredgers

A Cutter Suction Dredger is a stationary dredger equipped with a rotating cutting device (cutterhead) mounted to the end of a ladder and which cuts the material prior to being sucked up by flow of a powerfull suction pump. During the dredging process the Cutter Suction Dredger’s ladder is pulled near the cutterhead by two side wire winches from side to side and rotates horizontally in a radius of about 70-90 degrees. At the aft side of the Cutter Suction Dredger is fixed in the horizontal plane to the a certain position on the seabed, usually by means of a spud pole. After the material has been sucked up, it usually enters one or two powerful  inboard pumps, which pump the material via a floating line to e.g. a sandfill. A Cutter Suction Dredger is more suitable to dredge the harder materials.

Showing all 12 results

  • draga succion

    350mm (14″) suction dredger + push boat

    For Sale. Built 2015. Type: 350mm Damen Dop Dredger. Max dredging depth: 35 m. 565 kW hydraulic power pack driving DOP pump and winches. 285 kW jet pump set. Length floating line:        . Full flow control and monitoring system located in operating cabin. easy to operate. Includes a small pushboat tender with 5 t A-frame. Location: South America. Enquire

  • Cutter Suction Dredger

    500 mm (20″) Cutter Suction Dredger

    Direct from owners: Modular road/rail transportable, late nineties EU built, BV class. one inboard pump:  1.050 kW, cutter power: 140 kW, spud carrier and anchor booms. Far East. Price: Inquire

  • IHC cutter

    500mm (20″) Modular Cutter Suction Dredger

    2007, IHC Beaver 5014C, BV class. Modular. Loa x B x D (m): 35 x 9.5 x 2.5. Dredgepump power: 745 kW. location: NE Europe Enquire

  • IHC cutter

    500mm (20″) Modular Cutter Suction Dredger

    2013, IHC Beaver 5020C, BV class. Modular. Loa x B x D (m): 32.5 x 7.9 x 2.45. Dredgeing depth: 20 m. Dredgepump power: 745 kW. Location: Central America Enquire

  • Draga succión Cortador

    600 mm (24″) Cutter Suction Dredger

    Direct from owners: Dismountable (road transportable), Length: 36,00 m, Width: 8,00 m, Depth: 1,80 m. Cutter power: 145 kW, Total power: 1.080 kW, Dredging depth: 13,00 m. Location: Pacific Coast Central America. Price: Inquire

  • Draga IHC

    650mm (26″) modular Cutter Suction Dredger

    2013, IHC 65 DDSP, BV class. Modular. Loa x B x D (m): 58 x 12.5 x 3.0. Dredgepump power: 1,825 kW. location: Central America. Enquire

  • 28" dredger

    700mm (28″) Cutter Suction Dredger

    For Charter only. 2008, IACS class, IHC design Cutter Suction Dredger. Suction dia: 28″ (700mm), Max dredging depth: 25 m, Length over all: 98 m. Total installed power: 6150 kW, 1600 kW underwaterpump , 1800 kW inboard pump, 750 kW cutter drive, Anchor booms, Spud carrier, Cutter platform, 17 men accommodation. Enquire

  • Cutter dredger

    750 mm (30″) Cutter Suction Dredger

    Recent built, Length: 65,00 m, Width: 17,00 m, Depth: 4,20 m. Total installed power: 5.750 kW. Location: Western Europe. Price: Inquire

  • Cutter Dredger

    750 mm (30″) Cutter Suction Dredger

    Length oa: 64 m, Beam: 11.4 m. Max Dredging depth 18 m. Cutting power: 540 kW. Pump power: 1,675 kW. Spud carrier & Anchorbooms. Floating lines and assisting multicat ot tugboat available. For Charter only.

  • 32" dredger

    800 mm (32″) Cutter Suction Dredger

    BV class, length oa: 89 m, Beam: 18.5 m. max Dredging Depth: 27 m. Cutting power: 1,100 kW. Pump power: 5,800 kW. Floating lines and multicat or tugboat can be made available with the dredger. For Charter only

  • 850 dredger

    850mm (34″) Cutter Suction Dredger

    For Charter only. 2009, IACS class, IHC design Cutter Suction Dredger. Suction dia: 34″ (850mm), Max dredging depth: 27 m, Length over all: 116 m. Total installed power: 13,650 kW, 2,000 kW underwaterpump , 2 x 3,700 kW inboard double walled pumps, 1,100 kW cutter drive, Anchor booms, Spud carrier, Cutter platform, 21 men accommodation. Enquire

  • suction sandpit

    Suction dredger (modular)

    Unique modular sandpit-lake suction dredger. Built 2016. Production: approx 200 m³/hour. Dredger consisting of generator, submersible pump and 300 m x 300 mm floating line and 3 pontoons. Transportable on 4 truck trailers. Location: Baltic. Enquire
