Azimuth Stern Drive (ASD) Tug

This is a tug where normal propellers and shafts have been replaced by two azimuthing propulsion units, whereby each individual propeller/nozzle unit can rotate indepently (360 degrees) around a vertical axis. Also power can be applied individually to each unit. The position of the propulsion units are placed near the stern of the tug and makes it possible for the tug to move forwards, backwards, sideways and turn around its own axis with great precision. The towing point on an ASD tug is located on the foredeck; however some ASD tugs may have additional towing points on their aft deck, thus enabling them to function in a similar manner to a conventional twin-screw tug (but with increased manoeuvrability). Some ASD tugs have enhances features making them suitable for extended coastal towages (ocean towage), Anchor Handling, Fire Fighting, Offshore- or Escort applications.

Showing 1–12 of 42 results

  • Support FPSO

    100 tbp ASD FPSO FSV

    FPSO Support, AHT, Escort, Offshore Terminal, FiFi-1, Waterspray, Oil Rec

    2006. BV. L x B(m): 49.5 x 15.0: Fully equipped. 22 men accommodation Inquire

  • ASD escort

    100 tbp FiFi-1 OilRec ASD Escort Tug (+ sisters)

    90 tbp, Built: 2010, Class: BV, solid built & versatile, Dimensions (m): 31.5 x 11.0 x 5.4, Draft: 4.5, Fwd: independent double drum – 150 t hold, synthetic rope, Aft: independent double drum – 150 t hold. Enquire

  • ASD emergen

    108 tbp ASD Tug Escort (F,B,V,C), FiFi-1

    Escort (F,B,V,C), Offshore Terminal, FiFi-1, Waterspray, Oil Rec, Emergency Response

    Direct from Owners: Built 2015. Availability: Prompt. Rates: Inquire

  • ASD ice

    113 tbp ASD Tug Escort, FiFi-1, Ice Class

    Escort (F,B,V,C), Offshore Terminal, FiFi-1, Oil Rec

    Direct from Owners: Robert Allan Design. Built 2014. Steering Force 120 ton @ 10 knots. Availability: Prompt. Owners open to BB or BBHP. Rates: Inquire

  • ASD escort

    124 tbp ASD Tug Escort (F,B,V,C), FiFi-1 (2 sisters)

    Escort (F,B,V,C), Offshore Terminal, FiFi-1, Waterspray, Oil Rec

    Direct from Owners: Built 2008/2009. Availability & TC Rates: Inquire

  • pequen azimut

    24 tbp ASD tug

    2016 built, 24 tbp ASD tug. 2 x 360 kW, Fwd escort single drum winch, which can be fed underneath the accommodation to be used as a towing winch. small deck crane and 3-crew accommodation. Location Southern Europe. Enquire

  • azimut puerto

    40 tbp Escort ASD Tug (2 sisters)

    Harbour, Terminal, Escort, FiFi

    ABS. Built: 2009, Dimensions(m): 25.8 x 9.50 x 4,7, Fwd: Single drum – 70 t. brake load. Location: SE Asia, Price: Inquire

  • tbp ASD escort

    40 tbp Escort ASD Tug (2 sisters)

    Harbour, Terminal, Towage, Escort, FiFi

    NYK. Built: 1994, Dimensions(m): 30.00 x 9.60 x 4,35, Fwd & Aft: Single drum – 80 t. brake load. Location: SE Asia, Price: Inquire

  • ASD tug

    40-45 tbp ASD / VSP tugs (priced to sell)

    For Sale: From reputable owners, multiple early/mid nineties European built, attractively priced, well-maintained, ASD tugs ranging from 40-45 tbp. Location NorthSea. Enquire

  • berthing tug

    45 tbp ASD berthing tug (2 sisters)

    2004, solid design, well maintained 45 tbp ASD escort / berthing / mooring tug. L x B x D x draft (m):  29 x 9.0 x 4.7 x 3.8.  FiFi capability. Location: SE Asia. Enquire

  • ASD escort

    45 tbp ASD Escort Tug (2 sisters)

    Escort, Harbour, Coastal, Terminal & FiFi

    2008, BV Coastal, 2 x Niigata 6L25HX, 1.200 kW each, l x w x d (m): 28.00 x 9.80 x 4.00, bollard pull ahead/astern: 45/40 tons, forward/aft single drum 100 ton brake load, FiFi 2 x 600 m3/h, ME Gulf. Price: Inquire

  • ASD Escort

    45 tbp Escort ASD Tug (2 sisters)

    Harbour, Terminal, Escort, FiFi

    BV. Built: 2014, Dimensions(m): 29 x 10.50 x 4,95, Fwd: Single drum – 100 t. brake load. Location: SE Asia, Price: Inquire
