70 tbp ASD Escort Tug (2 sisters)
Towage, Offshore Terminal, Escort & FiFi-1
2016, ocean-going ASD, 70 tbp ahead, 63 tbp astern. Price (en-bloc or individual): Inquire
| General | |
| Built | 2016 |
| Class | ABS, ✠ A1, Towing Vessel, Escort Vessel, Ⓔ, |
| ✠ AMS, Fire-Fighting Vessel Class 1, | |
| Unrestricted Navigation | |
| Dimensions | |
| Length | 33.0 m |
| Breath | 12.2 m |
| Depth | 5.4 m |
| Draft | 5.2 m |
| GRT | 497 |
| Performance | |
| Bollard Pull (ahead) | 70 t |
| Bollard Pull (astern) | 63 t |
| Free Running Speed | 13 Knots |
| Tank Capacities | |
| Fuel Oil | 200 m3 |
| Fresh Water | 42 m3 |
| Foam | 10 m3 |
| Dispersant | 10 m3 |
| Machinery | |
| Main Engine | 2 x Cat 3516C, 2010 kW each |
| Azimuth Thruster | 2 x FPP Rolls-Royce |
| Generator | 2 x Cummins YP120, 120 ekW |
| Deck equipment | |
| Escort winch | 175 t brake, 2 x 200 m x 52 mm |
| Towing winch | 175 t brake, 800 m x 52 mm |
| Towing Hook | 70 t |
| Capstan | 3t x 0-15 m/min |
| Deck Crane | 1.0 t x 5 m, Palfinger PK6500M |
| Fire Fighting | |
| Class | FiFi-1 (FFS) |
| Pump | 1 x 2860 m3/hr |
| Monitors | 2 x 1200 m3/hr |
| Oil Dispersant | FFS |
| Navigation & Communication | |
| GMDSS System | Area A1+A2+A3 |
| Radar No. 1 | Furuno Far-2117 |
| Radar No. 2 | Furuno Far-8062 |
| GYRO Compass | Anschutz Standard 22 |
| Magnetic Compass | Lilley & Gillie MK2000 |
| AIS | Furuno FA-150 |
| GPS | Furuno GP-150 |
| Autopilot | Anschutz Nautopilot NP60 |
| Echo Sounder | Furuno FE-700 |
| VHF/FM | Furuno FM8900s |
| MF/HF | Furuno FS-2575T |
| Navtex Receiver | Furuno NX-700B |
| EPIRB | Ocean Signal 406MHZ |
| Accommodation | |
| Cabons | 10 crew |
