70 tbp ASD Tug NB (2 sisters)

Coastal – / Ocean towage, Terminal, Escorting, Mooring, FiFi-1, Salvage

RAmparts 3200, ASD, 70tbp, Class: RINa, solidly built & versatile, Dimensions (m): 32,00 x 11,60 x 5,40. Price: Inquire

SKU: C0015 Category: Tag:
GENERAL
Built 2017
Model RAmparts 3200
Class RINa, C ✠ TUG, ✠ AUT-UMS; Unrestricted Navigation;
            Fire-Fighting Ship 1; Water Spraying; MLC Design; Greenstar 3,
Escort Tug; Oil Recovery; Salvage Tug
DIMENSIONS
Length over all 32 m
Beam 11.6 m
Depth 5.4 m
Draft (max) 4.2 m
GRT 485

TANK CAPACITIES
Fuel oil 155 m³
Fresh water 40 m³
Waste oil / oily water 4.0 m³
Sewage holding tank 3.7 m³
Foam 15.4 m³
Dispersant  8 m³
MACHINERY
Main engines 2 x Cat 3516C D-rating, 2100 kW each @ 1600 rpm
Propulsion 2 x Schottel SRP 1515 CP
Nozzle Mild steel, stainless steel inner surface
Propellors 2600 mm dia
Generators 2 x Cat C9 DITA, 175 ekW each, 400V 50Hz
Aux genset  1 x Cat C4.4, 69 ekW

FIRE FIGHTING (external)
Class FiFi-1
Pump 2 x FFS SFP 250×350 – 1435 m³/h
Monitors 2 x FFS 1200 x 300 SB -1200/300 m³/h

PERFORMANCE
Speed (ahead, free running) 12.0 knots
Bollard pull 70 tonnes (approx.)

DECK EQUIPMENT
Escort winch Double drum, 2 x 160 m rope
Towing winch Single drum, 600 m x 52 mm wire
Towing hook 70 tonnes SWL
Reel winder 700 m wire

ACCOMMODATIONS
Cabins 2 x 1-berth, 3 x 2-berth
Total 8 crew
All cabins fully air-conditioned

OTHER EQUIPMENT
Anchor & chain 2 x 450 kg  HHP – chain 2 x 225 m, Ø24 mm
MOB crane GD RS 21/4
MOB 1 x 6 Pers. with outboard engine
Liferafts 2 x 10 Pers.
