48 tbp Shallow draft Ice class AHT
2014. Versatile Shallow draft Ice class AHT, 48 tbp, 2 x Cat. 3412, Double drum waterfall configured AH/Twoing winch. location: North Sea. Enquire
| General | |
| Built | 2014 |
| Class | BV, I ✠ Hull • Mach Tug Unrestricted navigation |
| • AUT-UMS (SS) , • Ice Class 1D | |
| Dimensions | |
| Length oa | 32.0 m |
| Beam | 10.0 m |
| Draft | 3.5 m |
| Operational draft | 2.9 m |
| GRT | 325 |
| Performance | |
| Bollard Pull | 48 ton |
| Free running speed | 11 knots |
| Machinery | |
| Main engines | 2 x Cat 3412, 1350 kW each |
| Propulsion | 2 x FPP, 4-blade ø2200 mm |
| Generator | 1 x 156 kVA |
| Harbour generator | 1 x 148 kVA |
| Bow thruster | 1 x 280 kW |
| Deck equipment | |
| AH / Towing winch | Double drum waterfall configuration |
| 1 x 100 ton pull, 125 ton hold, 480 m ø 48 mm | |
| 1 x 50 ton pull, 125 ton hold, 900 m ø 48 mm | |
| Towing pins | 2 x pins + stopper |
| Crane | Heila HLRM 200/20-4SL |
| Tank capacities | |
| Fuel | 160 m3 |
| Water | 55 m3 |
| Sewage | 6.0 m3 |
| Accommodation | |
| Cabins | 2 x 2-berth, 4 x 1-berth |
| Mess room/galley, sanitary, central heated, air conditioning | |
