DP-1 Fast shallow draft Survey Vessel
2005, DP-1, Shallow draft, solid built, Fast Survey Vessel. l x b x d(m): 32 x 7.2 x 3.5. Draft 1.55m. 10 pax accommodation. Speed: 26 knots cruising. Enquire
| General | ||
| Built | 2005 | |
| Class | BV I, ✠ Hull • Mach, Light ship multi | |
| purpose vessel, Sea Area 2, Dynapos AM/AT | ||
| Trading area | Coastal, Hs <2.5m | |
| Dimensions | ||
| Length o.a | 32.0 m | |
| Beam o.a. | 7.2 m / 9.8 m open side boards | |
| Depth | 3.5 m | |
| Draft | 1.55 m | |
| GRT | 160 | |
| Deck area | Fwd: 65 m2 / Aft: 80 m2 | |
| Performance | ||
| Max speed | 29 knots | |
| Cruising speed | 26 knots | |
| Tank capacities | ||
| Fuel capacity | 33.0 m3 | |
| Fresh water capacity | 2.4 m3 | |
| Machinery | ||
| Main engine | 2 x Cat. C32, 1081 kW each | |
| Propulsion | 2 x variable-pitch propellers | |
| Bow thrusters | 2 x tunnels of 63 kW | |
| Generators | Cat. C4.4 | |
| Harbour generator | Cat. C4.4 | |
| Deck Equipment | ||
| Crane | Heila 25 t |  |
| Sonar winch | 1 x | |
| ROV winch | 1 x | |
| ROV | Seaeye Falcon 191 | |
| Camera and sonar equipped with a hydraulic 10kg extended arm. 3 x 3200 Lumen lights. | ||
| Navigation | ||
| DP system | DP-1 Sirehna easy | |
| Autopilot | Anschutz Pilotstar D | |
| Radar | Furuno FAR-2117 | |
| GPS | Furuno GP-150D | |
| DGPS | 2 x Simrad MX521/MX610 | |
| Gyro | 2 x IXblue Quadrans | |
| SSB | Furuno FS-1575 | |
| Echo Sounder | Furuno GDS-101 | |
| SART | 2 x Jotron TronSART-20 | |
| Communication – GMDSS A3 station | ||
| VHF | 2 x Jotron TR-20 | |
| AIS | Furuno FA-150 | |
| EPIRB | Jotron Tron-60S | |
| Safety | ||
| Rescue boat | Promac BV RSQ 450G / 6 pers. | |
| Life rafts | 2 x 16 pers. | |
| Immersion suits | 16 | |
| Life jackets | 16 | |
| Rescue buoy | 3 | |
| Accommodation | ||
| Cabins | 2 x 1-berth, 4 x 2-berth | |
| Other | Galley, mess and sanitary facilities | |
