DP2 MPSV 90t/110t AHC crane

2007, BV, Loa 79.0 m, Width 18.0 m. DWT: +/-3200 ton. Deck cargo: 1240 ton, AHC deckcrane 110t/90t, 60t at 1.600 m, 70 pax accommodation. 150 persons rescue. ME Gulf. Inquire

SKU: B0093 Categories: , Tag:
General
Built 2007
Class BV, I ✠ Hull ✠ Mach Special Service – Stand by Rescue Vessel;
  Fire fighting ship / Fire fighting 1 Waterspray / Oil Recovery
  ✠ AUT-UMS; ✠ ALM; ✠ Dynapos-AM/AT-R; ✠ SDS

Dimensions
Length 85 m
Beam 18 m
Depth 7.40 m
Draft 3.10 m / 5.75 m
GT 4,300

Deck & Cargo capacities
Deadweight 3,200 t
Deck area 800 m² @ 10 t/m²
Mezzanine deck 260 m² @ 5 t/m²
Deck cargo 1,245 t

Machinery
Main generator 4 x 1,360 kW – 480 V
Propulsion 2 x 1,800 kW FP Azimuth
Bow thrusters 2 x 780 kW CP Tunnel
Bow thruster retractable 1 x 600 kW FP Azimuth
Emergency generator 1 x 320 kW – 480 V

Deck equipment
Crane #1 AHC knuckle boom
Harbour capacity DAF 1.2 – 110 t @ 14.5 m – 40 t @ 29.5 m
Offshore capacity DAF 1.6 – 90 t @ 13 m – 31 t @ 30 m
Main Winch 90 t / 61 t – 1,600 m – AHC
Auxiliary Winch 10 t / 10 t – 1,500 m – AHC – Man Riding
Crane #2 Knuckle boom
Harbour capacity DAF 1.2 – 24 t @ 10.5 m – 8 t @ 18 m
Offshore capacity DAF 1.6 – 12 t @ 10 m – 6 t @ 18 m
Main Winch 12 t / 7 t – 2,300 m – Man Riding
Tuggers 2 x 5 t
Capstans 2 x 5 t
Deck service air supply 1,200 m3/h @ 7 bars
Deck power 3 x 280kW – 480 V

Speed & Consumption
Speed 13 knots – 20 t/day
  10 knots – 15 t/day
In port 2 t/day
on DP 6 t/day

Tank capacities
Fuel oil 850 m³
Fresh water 370 m³
Drill water 1,840 m³
Anti-heeling 2 x 228 m³
Oil recovery 280 m³
Foam 25 m3

Dynamic positioning
Class DP 2, ADP21 Duplex System
Reference 1 DGPS 1 Thales Aquarius
Reference 2 DGPS 2 Thales Aquarius
Reference 3 Cyscan Laser Reference System
Reference 4 Sonardyne Fusion USBL

Fire Fighting
Class FiFi 1
Pumps 2 x 1,200 m3/h
Monitors 2 x 1,200 m3/h

Communication
Inmarsat 2 x Satcom
VSAT 1 x C band 256 Kbit
Video network YES

Accommodation
Cabins 10 x 1-berth, 24 x 2-berth
  4 x 3-berth
Other spaces 4 x offices, 1 x conference room
  1 x Hospital
  1 x Mess room, 2 x Day rooms,
  1 x Laundry, 1 x Galley, 1 x gym
