600 mm / 24″ Electric powered CSD
Unique electric powered 24″ CSD, capable to dredge up to 17 m. Location: Carribean. Enquire
| General | |
| Built / rebuilt | 2005 / 2011 |
| Dimensions | |
| Length oa | 52 m |
| Length pontoon | 40.5 m |
| Beam | 9.8 m |
| Depth | 2.15 m |
| Draft | 1.1 m |
| Lightweight | 425 t |
| Dredging particulars | |
| Dredging depth max | 17 m |
| Ladder | 22 m + 6 m extension |
| Spuds | 15 m + 12 m extension |
| Suction / delivery line | 600 mm / 600 mm |
| Cutter power | 520 kW |
| Jet pump | 225 kW |
| Side winches | 70 t @ 24 m/min |
| Machinery | |
| DC Elec. Dredge pump motor | 2600 kW, 600 VAC input @ 60 Hz |
| Shore power | 4,160 VAC |
| Power cable | 900 m, rated @ 8,000 V |
| Power cable reel | Barge mounted, diesel driven |
| Emergency power | Cat 3406 to operate winches |
| Spud winches | 150 kW |
| Ladder hoist winch | 150 kW |
