4,900 dwt heavy lift barge
2014 built Heavy lift barge with high deckload capacity. Immediately available. Location: Middle East Gulf. Enquire
| General | |
| Built | 2014 |
| Class | RINa, C ✠ Hull, Pontoon, |
| Unrestricted navigation | |
| Next SS due | May 2024 |
| Dimensions | |
| Length | 76.2 m (250 ft) |
| Beam | 24.4 m (80 ft) |
| Depth | 4.88 m (16 ft) |
| Draft | 3.62 m |
| GT | 2,300 |
| Deck & Cargo capacity | |
| Deadweight | 4,900 t |
| Deck load | 20 t/m2 |
| Clear deck area | 1,300 m2 (65 m x 20 m) |
| Features | |
| Salvage pump | Yes |
| Damage control box | Yes |
