1.475 kW Floating Dredge Booster Unit
Floating unit. Diameter (mm): Inlet/discharge: 600-750 mm
| GENERAL | |
| Year of Construction | 1978 |
| Yard | Dordrecht, The Netherlands |
| Working area | Inland waters |
| DIMENSIONS | |
| Length | 26,50 m |
| Width | 8,00 m |
| Draft | 1,65 m |
| Air draft | 6,20 m |
| VOLUMES / WEIGHTS | |
| Lightweight | 290 ton |
| Fuel capacity | 80 m3 |
| Ballast capacity | 30 m3 |
| BOOSTER PUMP SPECIFICATIONS | |
| Dredge pump | RE 165-60 |
| Inlet pipe diameter | 600/750 mm |
| Discharge pipe diameter | 600/750 mm |
| Max. pressure | 16 bar |
| MACHINERY | |
| Generator power | 300 kW |
| Booster pump / power | Caterpillar, 3516 B / 1.475 kW |
| Fuel | Marine diesel oil |
| MOORING SYSTEM | |
| Spuds | 2 |
| Spud lenght | 18,0 m |
| Diameter spuds | 500 mm |
| OTHER | |
| Road transportable | No |
| Dismountable | No |
| Remotely controlled | Yes |
Contact us for more details
