31 May 202343,000 DWT Semi-sub Barge
For Sale: Unique 140 m x 56 m Semi-sub barge. Location: Far East. Enquire
General | |
Built | 2009 |
IACS class | Semi-sub barge, Unrestricted |
Dimensions | |
Length | 140 m |
Beam | 56 m |
Depth | 8.8 m |
Draft | 5.6 m |
GT | 22,000 |
Semi-sub particulars | |
Deadweight | 43,000 t @ 5.75 m draft |
Submerged draft | 16.8 m |
Submerged main deck draft | 8.0 m |
Deck load | 10 t/m2, even distribution |
Deck area | 7,000 m2 |
Deck equipment | |
Mooring | 4 x 8.0 t HHP anchors |
Towers (l x b x h) | Fwd: 2 pc 12.8 m x 13.3 m x 25.2 m |
Aft: 2 pc 12.0 x 4.9 m x 28.2 m | |
Machinery | |
Generator | 2 x Cummins KTA 19, 300 kW ea |
Ballast pumps | 4 x 1,700 m3/h |
Compressor | 1 x 10 m3/h |
Ballast tanks | |
Total | 60,000 m3 |
