55m x 17m 4-PM Crane barge
Well maintained 4-poiint mooring pontoon / crane barge suitable for crane operation, marine construction works etc. Location: West Med (EU). Enquire
| General | |
| Built | 2005 |
| Class | DNV-GL, ✠ 100 A5 pontoon |
| Next SS due | 30 Nov 2020 |
| Dimensions | |
| Length | 55 m |
| Beam | 17 m |
| Depth | 3.65 m |
| Draft | 2.94 m |
| GT | 830 |
| Deck & cargo capacity | |
| Deadweight | 1,900 t |
| Deck load | 10 t/m2 |
| Deck equipment | |
| Mooring winches | 4 x 25 t + 2 x HPU |
| Wires | 4 x 200 m x 28mm |
| Anchors | 4 x 2.5 t Delta Flipper |
| Spuds | 2 x |
| Optional | |
| Crawler crane | Kobelco CKE 2750 (2017) |
| Capacity | 205 t @ 5.5 m |
| Boom | 21.3 m |
