400ft Heavy Lift Barge (2 sisters)
2011/2012, ABS class, unrestricted navigation. Deadweight abt. 18,850 t. SE Asia. For Charter only: Inquire
| General | |
| Class | ABS, ✠ A1, Barge |
| GRT | 9160 |
| Length Overall | 122 m (400’) |
| Breadth Moulded | 36.5 m (120’) |
| Depth Moulded | 7.6 meters (25’) |
| Deadweight | 18,850 t |
| Deck Loading | 25 metric t/m2 |
| Transv. / Longit. Bulkhead | 7 (watertight) / 4 (watertight) |
| No. of Compartments | 31 |
| Cargo Oil Tank Capacity | 4 x 500 m3 |
| Fresh Water Capacity | 2 x 700 m3 |
| Ballast System | 3 Cummins generators, 265 kW each |
| 4 x Electric Ballast Pumps 600 m3/h, 30 m head each | |
| Deck Equipment | |
| Mooring Bollards | 12 x double bollards each side (recessed) |
| 2 x double bitts bollards (raised) | |
| Towing Brackets | Fwd: 2 x smit bracket 400 t SWL |
| Aft: 1 x smit bracket 400 t SWL | |
| Winches | 1 x 10 tons double drum electric driven winch – 1 drum for |
| retrieving anchor and 1 drum for retrieving main tow gears | |
| Anchor | 1 x 3500 kg stockless |
| Fender | 4 rows half round fenders with 6 sets of |
| wooden padded fenders fitted on each side | |
| Manhole | 1 x flushed manhole for each tank – “T” bar locking type |
| Navigation Lights | 1 set solar powered |
| Pilot Ladders | 4 sets flush (pigeon holes) |
