65 tbp FiFi-1 CPP ASD Escort tug (2 sisters) (priced to sell)
2007 built RAmpart 3200 (2 sisters). BV class. Some AH features. Controllable pitch propellers. Location: Med. Enquire
| General | |
| Built | 2007 |
| Class | BV, I ✠ Hull ✠ Mach, Tug, Firefighting 1 |
| Unrestricted navigation | |
| Type | RAmparts 3200 |
| Dimensions | |
| Length | 32.0 m |
| Beam | 12.2 m |
| Depth | 5.4 m |
| Draft | 4.3 m |
| GT | 485 |
| Machinery | |
| Main engines | 2 x Niigata 6L28HX, 1838 kW each |
| Propulsion | 2 x CPP Azimuth |
| Generator | 2 x 260 kW |
| Performance | |
| Bollard pull | 65 t |
| Speed | 13 knots |
| Deck equipment | |
| Escort winch | Split drum, 60 t pull, 130 t brake |
| Towing winch | Single drum 60 t pull, 130 t brake |
| Tugger Winch | 1 x 10 t |
| Towing pins | yes |
| Shark Jaws | yes |
| Stern roller | yes |
| Crane | 1.5 t @ 10 m reach |
| Fire Fighting | |
| Class | FiFi-1 |
| Pumps | M/E driven |
| Monitors | 2 x 1200 m³/hr, facing aft |
| Water spray | yes |
| Tank capacity | |
| Fuel oil | 175 m³ |
| Potable water | 100 m³ |
| Foam | 18 m³ |
| Navigation & Communication | |
| Magnetic compass | Lilley & Gillie MK2000 |
| Echo sounder | Furuno FE-700 |
| VHF | Furuno FM-8800S |
| Radar | Furuno FR1510 Mk3 |
| GPS | Furuno GP-150 |
| Accommodation | |
| Cabins | 2 x 1-berth, 2 x 2-berth, 1 x 4-berth |
| Other | Messroom, galley, laundry, sanitary |
