6,000 m³ Hopper Dredger

2017, Non-China built, 6,000 m³ Trailing Suction Hopper Dredger. Class: Bureau Veritas with load line excemption. Siemens dredge/pump/discharge monitoring and control system. L x B x D x draft (m): 113 x 20 x 9.0 x 7.5. Dredging depth 30 m. Total installed power 15,940 kW. Speed loaded: 13.5 knots. Accommodation for 36 crew. Details available for named buyers. Enquire

SKU: A0141 Category: Tag:
General
Built 2017
Class BV,  I ✠ Hull ✠ Mach Hopper  Dredger
Unrestricted Navigation, CPS(WBT)
 Load line exemption Dredging within 15 miles from shore or
within 20 miles from port. Dredging over
15 miles from shore with Hs <2.5 m
Dimensions
Length 113 m
Beam 20 m
Depth 9.0 m
Draft (Summer / Dredg.) 6.0 m / 7.5 m
GRT 6800
Performance
Speed (mt/full) 100% MCR 14.5 / 13 knots
Hopper volume 6,000 m3
Deadweight (at dll) 8,900 t
Dredging related
Dredging depth 27 m
Dredge pipes 2 x
Dredge pumps 2 x 10,000 m3/h (water)
Jet pumps 2 x 3,000 m3/h @ 9.0 Bar
Overflow 2 x 1.8 m dia, 3.0 m stroke, conical, hydraulic
Bottom doors 2 x 6, conical
Discharge methods Dumping, rainbow, pump ashore
Deck cranes 2 x
Machinery
Main engines 2 x MAN 7L32/40, 3500 kW each
Propulsion 2 x CPP in nozzles
Bow thruster 1 x 450 kW tunnel
Dredge pumps 2 x MAN 9L21/31, 1740 kW each
Jet pumps 2 x MAN 6L21/31, 1290 kW each
Generators 4 x MAN 8L16/24, 720 kW each
Hydraulics Central system
Accommodation
Cabins 36 crew
