40 tbp Azimuth FiFi AHTS
2007, BV. Loa 48.0 m, width 12.8 m, depth 5.1 m, max draft 4.2 m. Deck Area 227 m2. Location: Far East. Price: Inquire
| GENERAL | ||
| Built: | 2007 | |
| Classification: | BV, I + Hull + Mach Special service Anchor | |
| Handling Tug, Unrestricted navigation + MACH | ||
| DIMENSIONS | ||
| Length: | 48.00 m | |
| Breath: | 12.80 m | |
| Depth / Draft: | 5.1 m / 4.2 m | |
| GRT: | 885 | |
| Deck Area: | 21.4 m x 10.6 m = 227 m² | |
| Deck Strength: | 5 tons / m² | |
| PERFORMANCE | ||
| Bollard Pull: | 40 t | |
| Max Speed: | 12 knots | |
| MAIN ENGINE / GENERATOR | ||
| Main Engine: | 2 x Caterpillar 3516B , 2375 bhp each | |
| Main Generator: | 3 x Caterpillar 3406C, 245 kW each | |
| Harbour Genset: | 1 x MANS @ 50 kW | |
| Propulsion: | HRP steerable thrusters | |
| Bow Thruster: | HRP – 5 tons | |
| DECK EQUIPMENT | ||
| AH / Towing Winch: | Double Drum – 100 tons @ 1st layer | |
| Wire Rope: | Work wire: 52 mm x 150 m | |
| Tow wire: 52 mm x 600 m | ||
| Tugger Winch: | 2 x 5 tons @ 15m / min | |
| Stern Roller: | 3.5 m x 1.5 m, 200 tons SWL | |
| Capstan: | 2 x 5 tons @ 15 m / min | |
| Sharkjaw / Towpin: | 200 tons SWL | |
| Crane: | 2 tons SWL @ 6 m | |
| SAFETY EQUIPMENT | ||
| Fire Fighting: | 2 x 600m³ / hr monitors | |
| Engine Room: | CO2 flooding system | |
| Life Raft: | 4 x 25 men self-inflatable | |
| Rescue Boat: | 1 x 6 men | |
| NAVIGATION / COMMUNICATION EQUIPMENT | ||
| Radar: | 2 x JRC – 48 nm / 96 nm | |
| Echo Sounder: | JRC JFE 582 | |
| AIS: | JRC, JHS – 182 | |
| GPS: | JRC JNav 50 | |
| Auto Pilot: | JRC, Comnav | |
| Compass: | JRC, Gyro Compass | |
| Sat Phone/ Fax/ | Fitted | |
| Inmarsat C: | JRC, JUE – 85 | |
| SSB: | JRC JSB 196GM | |
| VHF: | 1 x JRC JHS – 328 | |
| 3 x ACR 2729 A (Portable) | ||
| Navtex: | JRC, NCR 333 | |
| EPIRB: | JRC JQE – 3A | |
| SART: | 2 x JRC JQX– 30A | |
| Search Light: | 2 units – 2000W | |
| PA System: | 1 unit – Fitted | |
| Speed Log: | JRC, JLN – 205 | |
| TANK CAPACITY | ||
| Fuel Oil: | 684 m³ | |
| Fresh Water: | 255 m³ | |
| Lube Oil: | 5.0 m³ | |
| Hydraulic Oil: | 5.0 m³ | |
| Ballast: | 123 m³ | |
| Foam: | 9.2 m³ | |
| Detergent: | 15.0 m³ | |
| ACCOMMODATION | ||
| Cabin: | 2 x 1-berth, 3 x 2-berth, 4 x 4-berth | |
| Total: | 24 men | |
