7,250 m³ Hopper Dredger
2012, DNV-GL, Loa 120 m, Beam 21 m, Depth 7.7 m Draft 6.8 m. Available for Charter only: Inquire
| General | |
| Built | 2012 |
| Class | DNV-GL, 100 A5 “Hopper Dredger” RSA (50) at dredging draught 6.80 m, |
| unrestricted service at draught 5.70 m MC AUT | |
| Dimensions | |
| Length | 120.0 m |
| Width | 21.0 m |
| Depth | 7.70 m |
| Draft (int LL) | 5.70 m |
| Draft (dredg. LL) | 6.80 m |
| GRT | 6,725 |
| Speed | 11.5 knots |
| Dredging particulars | |
| Hopper volume | 7250 m³ |
| Deadweight | 9,900 t |
| Dredging depth | 35 m |
| Suction pipe | 1 x 1000 mm diameter |
| Bottom doors | 8 bottom doors |
| Pump ashore | Fitted, bow connection |
| Rainbow | Fitted, bow |
| Overflow | Fitted, conical |
| Machinery | |
| Main engines | 4 x Cat. 3516B, 1630 kW each |
| Propulsion | 2 x 1700 kW |
| Sand pump | 2.000 kW |
| Pump ashore pump | 2.000 kW |
| Jet pump | 1.000 kW |
| Bow thruster | 570 kW |
| Accommodation | |
| Cabins | 15 x 1-berth |
