Accommodation Work Barge (2 sisters)
5 septiembre 2016Self-propelled 132 pax AWB (2 sisters)
Autonomous operation. Location: WAF.(not Nigeria) For Charter only. Inquire
GENERAL | |
Built | 2006 |
Class | BV, I ✠ Hull ✠ Mach, Offshore service ship |
Accommodation, Coastal area | |
DIMENSIONS | |
Length | 70 m |
Beam | 20 m |
Depth | 4.30 m |
Draft max. | 2.30 m |
GT | 3,000 |
DECK CAPACITIES | |
Clear deck area | Abt 300 m2 |
Deck Cargo | 150 t |
Deck Strength | 220 m² @ 5 t/m² |
Deck Strength fwd | 80 m2 @ 10 t/m² (option crawler crane) |
Deadweight | 914 t |
MACHINERY | |
Main Engines | 4 x Baudouin M26SR V-type, 571 kW each |
Propulsion | 2 x 525 kW Azimuth |
Bow thruster | 270 kW |
Generators | 4 x 571 kW, 1 x 175 kW |
SPEED / CONSUMPTION | |
Speed | Abt 6 knots @ 6 m³/day |
At anchor | Abt 1.3 m³/day |
TANK / TRANSFER CAPACITIES | |
Fuel (MGO) | 277 m³, 65 m³/h |
Ballast (FW) | 810 m³ |
Fresh water | 500 m³, 50 m³/h |
Fresh water production | max 22 m³/day |
Dirty oil | 7 m³ |
ACCOMMODATION | |
Cabins | 8 x single, 7 x double, 20 x 4 & 6 x 6 |
Capacity | Total: 138 persons |
DECK EQUIPMENT | |
8-point mooring | 8 x 90 t, 1600 m x 38 mm wires |
Anchors | 8 x 5 tons Flipper-Delta |
Bow ramp | Open – manual operated N/A |
Deck Crane | 9.3 tons outreach 13.3 m (stb side) |
Rescue boats | 2 x 10 knots, 6 persons each |
Boat landings | 2 x Surfer landings |
