800 mm (32″) Cutter Suction Dredger
BV class, Length oa: 89 m, Beam: 18.5 m. max Dredging Depth: 27 m. Cutting power: 1,100 kW. Pump power: 5,800 kW. Floating lines and multicat or tugboat can be made available with the dredger. Enquire
| General | |
| Built | Mid eighties |
| Class | BV, I ✠ Hull, Dredger,-no propulsion, |
| Unrestricted navigation | |
| Dimensions | |
| Length overall | 89 m |
| Length pontoon | 67 m |
| Beam | 18.5 m |
| Depth | 5.0 m |
| Draft (max) | 4.0 m |
| GT | 1,698 |
| Deck equipment | |
| Side wire winches | 60 t @ 16 m/min |
| Crane | Travelling type |
| Dredging particulars | |
| Suction pipe | 0.80 m |
| Discharge pipe | 0.75 m |
| Dredging depth (min/max) | 6.5 m / 27.5 m |
| Spud carrier | Yes |
| Anchor booms | Yes |
| Cutter platform | Yes |
| Machinery | |
| Cutter power | 1,100 kW |
| Ladder pump | 1 x 1,060 kW |
| Inboard pump | 2 x 2,380 kW |
| Jet pump | 1 x 560 kW |
