Length oa: 64 m, Beam: 11.4 m. Max Dredging depth 18 m. Cutting power: 540 kW. Pump power: 1,675 kW. Spud carrier & Anchorbooms. Floating lines and assisting multicat ot tugboat available. For Charter only.
GENERAL | |
Class | Inland / Sheltered waters |
DIMENSIONS | |
Length overall | 64.0 m |
Length pontoon | 50.0 m |
Breadth | 11.4 m |
Depth mld | 2.85 m |
Max. draft | 1.91 m |
Normal draft | 1.85 m |
GRT | 341 |
DREDGING PARTICULARS | |
Suction pipe diameter | 750 mm |
Discharge pipe diameter | 650 mm |
Max. dredging depth | 18.0 m |
Min. dredging depth | 2.90 m |
Anchoring system | Spud carriage + Anchor booms |
MACHINERY | |
Cutter output | 544 kW |
Inboard pump output | 1,678 kW |
Total installed power | 2,541 kW |
