26m utility AHT (3 sisters)
Towing, Anchor Handling, Utility and Dredge Support
2008, GL. l x w x d (m): 26.0 x 9.2 x 3.6, max. draft 2.8 m. 2 x Cat 3412, 720 bhp each, 12.6 tbp. telescopic crane: 60 tm. Far East. Inquire
| GENERAL | |
| Built: | 2008 |
| Classification: | GL, + 100 A5 Tug (+) MC |
| DIMENSIONS | |
| Length Overall : | 26.0 m |
| Breadth: | 9.2 m |
| Depth / Draft: | 3.6 m / 2.8 m |
| GRT: | 225 |
| MACHINERY | |
| Main Engine: | 2 x Caterpillar 3412 DITA, 720 bhp each |
| Main Generator: | 2 x Cummins, 78 kW each |
| Gearbox: | Twin Disc MG5222 Ratio 6:10:1 |
| Propulsion: | 2 x FPP |
| PERFORMANCE | |
| Bollard Pull: | 12.6 ton |
| Max Speed: | 10 knots |
| DECK EQUIPMENT | |
| AH/Towing Winch: | ME Single Drum Hydraulic |
| 40T @ 1st layer. | |
| Brake Holding 80T | |
| Drum Capacity: | 38m x 400m |
| Crane: | ME Telescopic type 60 t/m |
| SWL 5T @ 12m | |
| Stern Roller: | Fitted |
| Clear Deck Space: | 80.8m2 |
| SAFETY EQUIPMENT | |
| Life Jacket: | 14 pax |
| Life Raft: | 2 x 10 men, SOLAS standard |
| Life Buoy: | 8 sets, SOLAS standard |
| NAVIGATION / COMMUNICATION EQUIPMENT | |
| Radar: | Furuno 1831 – 32 Nm |
| GPS: | Furuno GP – 31 |
| Magnetic Compass: | Type T – 150B |
| VHF: | Furuno FM3000 |
| Echo Sounder: | Furuno 1831 FCV -66 |
| EPIRB: | GME 406mHz |
| PA System: | Fitted |
| TANK CAPACITY | |
| Fresh Water: | 60m3 |
| Fuel Oil: | 90m3 |
| ACCOMMODATION | |
| Single Cabin: | 2 units |
| 2 men Cabin: | 3 units |
| Total: | 8 men |
