Fast Crew Supplier, DP-1 FiFi-1
5 septiembre 2016
FSIV (Fast Intervention & Supply Vessel)
5 septiembre 2016
Fast Crew Supplier (2 sisters)
2009, Sea Axe bow, mono hull, waterspray, l x b x draft (m): 36.00 x 7.35 x 3.00, Speed: 26 knots, propulsion: 3 x 1,040 kW, fixed props. 30 pax + 6 crew. Adriatic. For Charter only: Inquire
| GENERAL | |
| Built | 2009 |
| Hull | Aluminium |
| Superstructure | Aluminium |
| Class | Bureau Veritas / CRS |
| Notation | I + HULL • MACH, Crew boat, Coastal area restricted open sea service (Hs < 4 m) (100nm from shore) |
| DIMENSIONS | |
| Length over all | 35.95 m |
| Width | 7.33 m |
| Depth | 3.30 m |
| Draft | 2.00 m |
| GT | 170 |
| CAPACITIES | |
| Fuel | 28.00 m3 |
| Portable Water | 25.00 m3 |
| Waste Water | 0.50 m3 |
| Dirty Oil | 0.50 m3 |
| Deck Tanks | 2 x 5.00 m3 |
| Deck Space | 120.00 m2 |
| Deck Strength | 1.4 t/m2 |
| PERFORMANCE | |
| Max Speed (trials) | 28 knots |
| Cruise Speed | 26 knots |
| PROPULSION | |
| Main Engines | 3 x Caterpillar x C32 C (WOSR) |
| Total Power | 3.132 bkW @2100-2300rpm |
| Gearbox | 3 x Reintjes WVS730 |
| Propellors | 3 x Fixed pitch propellers |
| ELECTRICAL EQUIPMENT | |
| Generators | 2 x 60 kW; 230V/400V 50Hz |
| DECK LAY-OUT | |
| Anchor | According to classification regulation |
| Anchor Winch | Electrically operated |
| Crane | 1 x Effer 6000-1S (2t @ 5m) |
| LIFE SAVING EQUIPMENT | |
| Life Buoys | 4 |
| Life Jackets | 40 |
| Life Rafts | 2 x RDF 25 persons |
| Fireman’s Outfit | 2 x incl. 2 x fire axes |
| Fast Rescue Craft | 4,70 m MOB with outboard motor 25 hp |
| Fire-fighting (internal) | Fixed gas flooding system Engine Room |
| Portable extinguishers according to class | |
| AUX. SYSTEMS | |
| Fire-fighting (external) | 1 x monitor 6.000 ltr/min |
| Spray Booms | 82 litres seawater/min |
| Spray Shield on Deck | Fitted around the hull at deck level |
| Mech. Ventilation | Axial flow fans |
| Bow Thruster | 1 x 75 kW, Hydraulic |
| ACCOMMODATION | |
| Cabins | 2 x 1 & 2 x 2 persons |
| Passenger seats | 30 |
| Air-conditioning | wheelhouse and accommodation |
| Crew | 6 |
| Passengers | 30 |
| NAVIGATION & COMMUNICATION | |
| Searchlight | 2 x 500 Watt |
| Radar | 2 x JRC JMA – 5106 |
| Magnetic Compass | Ritchie HB 71 |
| Echo Sounder | Raymarine ST 40 |
| GPS | NWZ – 4570 |
| VHF | Sailor 2048 / Sailor RT 5022 |
| HF / MF | Sailor CU 5100 |
| PA | Alphatron Marine |
| SATCOM | NERA FLEET 33 |
| NAVTEX | JCR NCR – 333 |
| Autopilot | NAUTOPILOT NP 60 |
| AIS | JHS – 182 |
