25 tbp Harbour tug
1979, solid built tug, twin prop, 2 x Cat 3512. Loa: 26.0 m, Beam: 8.5 m. Pacific coast Central America. Inquire
| General | |
| Built | 1979 |
| Shipyard | Merwede, the Netherlands |
| Class | SAC on behalf of the flagstate |
| Dimensions | |
| Length overall | 26.0 m |
| Beam | 8.5 m |
| Depth | 4.2 m |
| Max Draft | 3.85 m |
| GRT | 195 |
| Performance | |
| Bollard pull | 25 t |
| Speed | 10 Knots |
| Tank Capacities | |
| Fuel Oil | 38 m3 |
| Fresh Water | 40 m3 |
| Accommodation | |
| Crew | 8 |
| Machinery | |
| Main engines | 2 x Caterpillar 3512, 1200 bhp each |
| Generator | Detroit Diesel 471 |
| Propulsion | Kamewa |
| Deck Equipment | |
| Towing Winch | 2 x Jordao, 300 m, 1¼» diameter, 35 t |
| Towing Hook | 30 t SWL |
| Deck Space | 90 m2 |
| Fire Fighting | |
| Pumps | 2 x 360 m3/hr |
| Monitors | 2 x |
| Radio & navigation equipment | |
| VHF | 1 x ICOM IC-M302, |
| 1 x ICOM IC- M422 | |
| AIS | 1 x Furuno FA-150 |
| VMS | 1 x Ultrack 12 VDC |
| Radar | 1 x Furuno 3361-7706, |
| 1 x Furuno 4361-7208 | |
| GPS | 1 x Furuno 6432-2460 |
| Echosounder | 1 x Furuno 8072-1186 |
| Navtex | 1 x Furuno 004402 |
