26 tbp Coastal Tug
Coastal Towing, Barge Handling, General Support
2006, DNV-GL. l x w x d (m): 30.00 x 8.6 x 4.3, 2 x Cat 3508, 750 kW each. Location: Far East. Inquire
| GENERAL | |
| Built: | 2006 |
| Classification: | DNV-GL |
| DIMENSIONS | |
| Length: | 30 m |
| Breath: | 8.6 m |
| Depth / Draft: | 4.3 m / 3.6 m |
| GRT: | 270 |
| Bollard Pull: | 26 tons |
| MAIN ENGINE / GENERATOR | |
| Main Engine: | 2 x Cat. 3508B, 1000 bhp each |
| Main Generator: | 2 x Cummins, 78 kW each |
| Gear Box: | 2 x Twin Disc MG5301 |
| Propulsion: | 2 x Fixed pitch propeller |
| Max Speed: | 10 knots |
| DECK EQUIPMENT | |
| Towing Winch: | 15 tons / 90 tons brake |
| Wire Rope: | Tow wire : 36 mm x 600 m |
| SAFETY EQUIPMENT | |
| Fire Fighting: | 2 x 600 m³/hr monitor |
| Life Rafts: | 2 x 15 men |
| Life Jackets: | 14 units |
| OTHER INFORMATION | |
| Deck Space: | 8.5 m x 6.2 m = 52.7 m² |
| Deck Strength: | 5 tons / m2 |
| NAVIGATION / COMMUNICATION EQUIPMENT | |
| Radar: | Furuno FS – 1532 |
| Echo Sounder: | Furuno FCV – 667 |
| GPS: | Furuno GP – 32 |
| Auto Pilot: | Simrad AP32 |
| Compass: | Magnetic type – Daiko Keiki |
| Inmarsat C: | Fitted |
| SSB: | Furuno FS – 1570 |
| VHF: | Furuno FM880S |
| Navtex: | Furuno NX – 700B |
| EPIRB: | Samyung SEP406 |
| SART: | 2 x ACR 9GH |
| PA System: | Fitted |
| TANK CAPACITY | |
| Fuel Oil: | 245 m3 |
| Fresh Water: | 35 m3 |
| Lube Oil: | 3 m3 |
| Dirty Oil: | 7 m3 |
| Ballast: | 37 m3 |
| ACCOMMODATION | |
| Cabin: | 2 x 1-beth, 1 x 2-berth, 1 x 8-berth |
| Total: | 12 men |
