46 tbp FiFi-1 ASD tug
Harbour, Terminal, Escort, FiFi
BV. Built: 2012, Dimensions(m): 29 x 10.50 x 4,95, Fwd: Single drum – 100 t. brake load. Location: SE Asia, Price: Inquire
| GENERAL | |
| Built | 2012 |
| Class Notation | BV, I ✠ Hull, ✠ Mach. Tug |
| DIMENSIONS | |
| Length O.A | 29.0 m |
| Breadth Moulded | 10.5 m |
| Depth Moulded | 5.0 m |
| Draft (Operations) | 3.9 m |
| GRT | 350 |
| PERFORMANCE | |
| Bollard Pull | 46 t |
| Speed | 12 knots |
| MACHINERY | |
| Main Engines | 2 x NIIGATA 6L25, 1323 kW each |
| Propulsion | 2 x Niigata ZP-21 Azimuth |
| Generators | 2 x Volvo Penta, 108 kW |
| DECK EQUIPMENT | |
| Fwd Escort winch | Pull 5 t, hold 100 t |
| Drum Capacity | 1 x 12” Circ x 200 m rope |
| Towing Hook | 50 t remote release |
| Deck Crane | 1 x 1 ton, reach: 5 m |
| FIRE FIGHTING & OIL REC | |
| Fire Pump | 1 x 1400 m3/hr @130 m head |
| Fire Monitors | 2 x 600 m3/hr with remote control |
| Oily Water Separator | 0.5 m3/hr |
| Dispersant System | 1 x dispersant pump c/w 2 x veejet nozzle |
| TANK CAPACITIES | |
| Fuel Oil | 160 m3 |
| Fresh Water | 32 m3 |
| Foam Tank | 7.0 m3 |
| Dispersant Tank | 7.0 m3 |
| NAVIGATION & COMMUNICATION (A1 + A2 +A3) | |
| Radar | 1 x JRC JMA-5212 |
| GPS Navigator | 1 x Koden KGP-920 |
| Inmarsat C | 1 x Furuno Felcom 15 |
| MF/HF | 1 x Furuno FS 1575/NBDP |
| AIS | 1 x Furuno FA-150 |
| Speed Log | 1 x Furuno DS-80 |
| Echo Sounder | 1 x Furuno FE 700 |
| VHF Radio Telephone | 2 x Furuno FM-8800S |
| Navtex Receiver | 1 x Furuno NX-700B |
| GPS Compass | 1 x Koden KGC-1 |
| Magnetic Compass | 1 x Saura Keiki MR 150 A |
| EPIRB | 1 x McMurdo E5 |
| BNWAS | 1 x BR-500 |
| ACCOMMODATION | |
| Complement | 10 men (air conditioned) |
| Cabins Total | 2 x 4-men cabins and 2 x 1-man cabin |
