700mm (28″) Cutter Suction Dredger
For Charter only. 2008, IACS class, IHC design Cutter Suction Dredger. Suction dia: 28″ (700mm), Max dredging depth: 25 m, Length over all: 98 m. Total installed power: 6150 kW, 1600 kW underwaterpump , 1800 kW inboard pump, 750 kW cutter drive, Anchor booms, Spud carrier, Cutter platform, 17 men accommodation. Enquire
| General | |
| Built | 2008 |
| Design | IHC |
| Class | CCS, ★ CSAD Cutter suction dredger, |
| dredging within 20 nautical miles from shore | |
| Dimensions | |
| Length oa | 98 m |
| Length hull | 64.5 m |
| Beam | 15 m |
| Depth | 4.0 m |
| Draft | 2.55 m |
| GRT | 1250 |
| Performance | |
| Pump capacity | 2,500 m3/h – 3,500 m3/h |
| Dredging depth | 25 m |
| Machinery | |
| Submerged pump engine | 1 x Caterpillar 3516B HD, 1825 kW |
| Inboard pump engine | 1 x Caterpillar 3516B HD, 1825 kW |
| Hydraulic pump engine | 1 x Caterpillar 3512 B HD, 1425 kW |
| Generator engine | 2 x Cummins KTA 19-B(M), 445 kW |
| Alternator | 2 x 400 kW, 400 V, 50 Hz |
| Dredging / Deck equipment | |
| Suction / delivery diameter | 700 mm / 700 mm |
| Submerged pump | 1 x IHC, 1625 kW |
| Inboard pump | 1 x IHC, 1825 kW |
| Cutter head / Drive | IHC, 2200 mm / 750 kW |
| Spud | 2 x 37 m x 1.2 m, 49 t each |
| Spud carrier | 6.2 m stroke |
| Spud tilt system | Yes |
| Anchor booms | Yes |
| Cutter platform | Yes |
| Deck cranes | 1 x 13 t, 1 x 11 t, 1 x 3.5 t |
| Tank capacities | |
| Fuel | 280 m3 |
| Fresh water | 128 m3 |
| Hydraulic oil | 11.5 m3 |
| Accommodation | |
| Cabins | 3 x 2-berth, 1 x 3-berth, 2 x 4-berth |
| Complement | 17 crew |
