Versatile workboats, Dredging support, Diving support, Cable repair, Supply, Anchor handling
2010, BV. l x w x d (m): 28.00 x 11.00 x 3.25, Draft 2.50 m. Propulsion 2 x Cat 3412, bollard pull 14 tons. Knuckle boom crane, anchor winch, bow & stern roller. Accommodation for 10 crew. Location: Far East Inquire
GENERAL | |
Built: | 2010 |
Classification: | BV, I + Hull + Mach, Special service / Work Boat |
Unrestricted navigation, + MACH | |
DIMENSIONS | |
Length: | 28.0 m |
Breath: | 11.0 m |
Depth / Draft: | 3.25 m / 2.50 m |
GRT: | 270 |
PERFORMANCE | |
Bollard Pull: | 14 tons |
Deck Strength: | 5 t/m² |
MAIN ENGINE / GENERATOR | |
Main Engine: | 2 x Caterpillar 3412C DITA, 720 bhp each |
Generator: | 2 x Cummins, 83 kW each |
Gear Box: | Twin Disc MGX 5222 |
Propulsion: | 2 x FPP in Kort nozzles |
DECK EQUIPMENT | |
Towing Winch: | 1 x 25 tons pull, 60 tons brake holding |
Wire Rope: | 32 mm x 400 m |
Stern / Forward Roller: | Fitted |
Crane: | knuckle boom SWL 7 tons @ 8.4 m |
SAFETY EQUIPMENT | |
Fire Detection: | Smoke / Heat Detectors – Fitted |
Engine Room: | CO2 flooding system |
Life Raft: | 2 units – 10 men |
NAVIGATION / COMMUNICATION EQUIPMENT | |
Radar: | JRC JMA 2343 |
Echo Sounder: | JRC FF60 |
GPS: | JRC NWZ 4551 |
Compass: | Daiko Magnetic Compass |
Anemometer: | Wizard III |
SSB: | JRC JSB 196 |
VHF: | GX 600 |
Navtex: | JRC NCR 333 |
EPIRB: | McMurdo E3 |
PA System: | Seamate PA50 |
TANK CAPACITY | |
Fuel Oil: | 168 m³ |
Fresh Water: | 62 m³ |
ACCOMMODATION | |
Cabin: | 3 x 2-berth cabin, 1 x 4-berth cabin |
Total: | 10 berth |
2008, BV. Loa 76.0 m, width 20.00 m, depth 6.10 m, max draft 4.50 m. Deck Area 7000 m2. DW 2,200 tons. Deck crane 40 tons. 138 berths. Location: Far East. Price: Inquire
2008, ABS, Singapore Flag. Loa 54.00 m, width 13.80 m, depth 4.50 m, max draft 3.80 m. DW 950 tons. Deck Area 240 m2. Towing/AH winch waterfall conf. Stern Roller, A-frame Seating. Dedicated ROV generator. Price: Inquire
Well equipped and documented. L x W x Depth x Draft (m): 92.00 x 31.50 x 6.70 x 5.30. Deadweight: 11,000+ ton. Deck area: ~2,700 m2. Max submerging depth fwd: 2.0 m above deck, aft: 6.3 m above deck. For Charter only: Inquire
