Towing, Mooring, Fire Fighting, & Pollution Control
2007, LRS, l x w x d (m): 26.00 x 8.00 x 3.95, 2 x Cat 3512, 2,850 kW, Caribbean. Inquire
General | ||
Class | LRS + 100 A1 Tug + LMC | |
Built | 2007 | |
Dimensions | ||
Length over all | 26.0 | m |
Width | 8.0 | m |
Draft (max.) | 3.95 | m |
Deck area | 80 | m² |
GT | 176 | |
Deadweight | 52 | ton |
Machinery & propulsion | ||
Main engine | 2 | Caterpillar 3512B TA HD+/B |
Total power | 2,850 | kW |
Propulsion | 2 | fixed pitch |
Performance | ||
Speed | 13,2 | knots |
Bollard pull (ahead) | 52 | ton |
Tank capacity | ||
Fuel oil | 80 | m³ |
Potable water | 12 | m³ |
Oil dispersant | 3 | m³ |
Accommodation | ||
Accommodation | 8 | crew |
Navigation & communication | ||
Echo sounder | Furuno LS 6100 | |
VHF | “Sailor” Compact RT5022 | |
Radar | Furuno FR-8062 | |
GPS | Furuno GP-150 | |
Autopilot | Simrad AP 50 | |
SSB Radio Telephone | Furuno FS-1570 | |
Navtex | Furuno NX-700 | |
Inmarsat | 2 | Furuno Felcom 15 |
AIS | Furuno FA-150 | |
Deck equipment | ||
Towing hook | ||
Towing / anchor handling winch | ||
Other equipment | ||
Fire-fighting monitors | 2 | |
Capacity each monitor | 1200 | m³/hr |
Ocean & Coastal Towage, Anchor Handling and Supply
2009, ABS class, DP-1, FiFi-1. l x w x d (m): 58.60 x 14.50 x 5.5, 2 x Wartsila 9L20 1,800 kW each, Towing/AH winch waterfall configuration. Sternroller and other AH related equipment. Inquire
2009, ABS. Loa 75.40 m, width 16.80 m, depth 7.50 m, max draft 6.10 m. DW 2,190 tons. Deck Cargo 1,000 tons. Deck Area 500 m2. Location: Far East. Price: Inquire
A-Frame: AXTech, SWL 250t (double fall), 200t (single fall), phi= 1,3
Including: Certificates, Approved drawings, Manuals, Spare parts, Load charts, etc. Condition: very good. Price: Inquire
