50 tbp FiFi Escort ASD Tug
Available: Q1 2021. Solid built, Location: SE Asia. Enquire
| General | |
| Built | 1983 |
| Class | DNV-GL, 1A1 Tug E0 |
| Next SS due | May. 2023 |
| Dimensions | |
| Length o.a. | 32.0 m |
| Beam | 10.6 m |
| Depth (moulded) | 5.34 m |
| Draft | 4.8 m |
| GT | 430 |
| Performance | |
| Speed | 13.5 knots |
| Bollard pull | Ahd 50 t, Ast 46 t |
| Deadweight | 305 t |
| Clear deck space | 41 m2 @ 5 t/m2 |
| Machinery | |
| Main engines | 2 x Daihatsu 6DSM, 1325 kW each |
| Propulsion | 2 x Niigata Z-peller |
| Generators | 2 x Cat. 3306, 125 kVA each |
| FiFi pump engine #1 | 1 x Cat. 3412, 415 kW |
| FiFi pump engine #2 | 1 x Cat. 3305, 150 kW |
| Deck equipment | |
| Escort winch | 200 t hold, rope |
| Towing winch | 200 t hold, wire c/w warping heads |
| Towing hook | 60 t |
| Towing / Guide pins | 2 sets |
| Capstan | 1 x Hydraulic |
| Stern roller | 1 x |
| Fendering | Bow and aft quarters solid, rest tires |
| Tank capacity | |
| Fuel | 145 m3 |
| Freshwater | 46 m3 |
| Foam | 13.5 m3 |
| Accommodation | |
| Cabins | 2 x 1-berth, 4 x 2-berth |
