For Sale. Built 2015. Type: 350mm Damen Dop Dredger. Max dredging depth: 35 m. 565 kW hydraulic power pack driving DOP pump and winches. 285 kW jet pump set. Length floating line: . Full flow control and monitoring system located in operating cabin. easy to operate. Includes a small pushboat tender with 5 t A-frame. Location: South America. Enquire
General | |
Type | 350 mm suction dredger |
Built | 2015, Damen, the Netherlands |
Dimensions | |
Length | 17.0 m |
Beam | 6.0 m |
Depth | 1.6 m |
Machinery | |
Dredge pump | Submersible Damen DOP 350 |
Suction/Discharge | 350 mm (14”) |
Production rate | 950 m3/h (max) |
Dredging depth | 35 m (max) |
Power Pack DOP pump | Volvo TAD 1643VE, 565 kW |
Hydraulic pumps | 2 x 900 ltr/min, 350 Bar |
Power Pack Jet pump | Iveco Eng. 285 kW |
Pump | 600 m3/h @ 9.4 Bar |
Deck equipment | |
4-point mooring winch | 4 x 4 t pull |
DOP pump hoist winch | 12 t pull |
Dredge control & monitoring | Cabin with full instruments |
Push boat / Tender | |
Length | 12 m |
Beam | 4.8 m |
Depth | 1.2 m |
Outboards | 2 x 115 hp Mercury |
Power pack | 15 hp diesel driven |
A-frame / Winch | 5 t pull |
Diesel tank | 5.0 m3 |
Modular 40 ft container transportable |
Mono hull, fixed props
ABS. L x b x d (m): 40.00 x 7.50 x 3.25. Draft 2.30 m. Speed: 27.8 knots, 114 m2 deck area, propulsion: 3 x fixed props totalling 4,500 bhp. 60 pax + 10 crew. Price: Inquire
Mono hull, fixed props
New. Prompt delivery. IACS class. L x b x d(m): 40.00 x 8.20 x 3.65. Draft 2.00m. Speed: 27 knots cruise with 50 ton deadweight / 18 knots cruise fully laden, 115 m2 deck area, propulsion: 3 x 1,350 kW, fixed props. 100 pax + 10 crew. Price: Inquire
Terminal and Escort
2015, Aft towing winch 55 ton, brake holding 110 ton, fwd winch 55 ton, brake holding 115 ton. Price (en-bloc or individual): Inquire
