68 tbp AHTS FiFi-1

2010, ABS. Loa 50.0 m, width 13.20 m, depth 5.20 m, max draft 4.50 m. DW 800 tons. Deck cargo: 600 t. Deck Area 250 m2. Location: Australasia. Inquire

Artikelnummer: B0063 Categorieën: , Tag:
PARTICULARS
Year Built 2010
Classification ABS, A1, Towing Vessel, AH, Fire Fighting Vessel
            Class 1, Offshore Support Vessel, AMS

DETAILS
Length Overall 50.00 m
Breadth 13.20 m
Depth Moulded 5.20 m
Maximum draft 4.50 m
GT 1,090
Deadweight 800 mt
Clear deck Space 250 m²

PERFORMANCE
Max Speed 12.5 kts
Bollard Pull tonnes 68.5 t

CAPACITY
Fuel Oil 590 m³
Fresh Water 215 m³
Ballast Water 150 m³

MACHINERY
Main Engines 2 x Caterpillar 3516B, 1,920 kW each
Propeller BERG Propulsion 2 x CPP, KA-4 type
Generators 3 x Cummins 415V/3/50, 350 kW each
Bow Thruster 5 mt thrust, Kamewa thruster
DECK EQUIPMENT
Towing/AH Winch Double drum waterfall winch, each drum
SWL 150T t @ 6m/min, 1st layer.
Capacity 2 x 56 mm x 1250 m long
Wire Ropes 1 x 58 mm dia x 840 m (towing wire)
1 x 56 mm dia x 1250 m (working wire)
1 x 56 mm x 1000 m (spare tow wire)
Shackles and Bridles Assorted from SWL 50 mt to 200 mt
Tugger Winches 2 x 10 t @10m/min, brake holding 25 tons
Capstan 1 x 5 t @ 10 m/min
Towing Pins 200 t SWL 2 Off
Shark Jaw 200 t, triplex shark jaw
Stern Roller 4 m x 1.5 m
Deck crane 10 ton @ 2 m Electro-hydraulic telescopic

ACCOMMODATION
Berths 4 x 1, 3 x 2, 5 x 4
Total 30

FIRE FIGHTING
Class FiFi-1
Monitors 2
Capacity 2,400 m³/hr capacity
Foam 2,000 ltrs foam tank
Oil Dispersant Oil dispersant boom P&S
