8000 m3 Trailing Suction Hopper Dredger
2018 built, modern and complete Hopper Dredger with Ice class notation, well-equipped with frequency driven dredge pumps and jet pumps as well as machinery and components from reputable manufacturers. High value unit. Only serious buyers to enquire
| General | |
| Built | 2018 |
| Class | IACS, Trailing Suction Hopper Dredger, |
| Ice Class B | |
| Dimensions | |
| Length | 123 m |
| Beam | 25 m |
| Depth | 8.90 m |
| Draft (DLL*) | 7.70 m |
| GT | 9,900 |
| Dredging particulars | |
| Hopper volume | 8,000 m3 |
| Deadweight (DLL*) | 12,350 t |
| Speed | 14 knots |
| Endurance | 20 days |
| Dredging equipment | |
| Dredge pipes | 2 x 800 mm |
| Dredging depth | 32 m / 40 m / 60 m |
| Discharge method | 2 x 10 bottom doors |
| Bow connection, rainbow | |
| Overflow | 1 x |
| Machinery | |
| Main engines | 2 x MAN 9L32/40, 4500 kW ea |
| Propulsion | 2 x CPP in nozzles |
| Bow thrusters | 2 x 350 kW elec. drive |
| Generators | 2 x M/E driven shaft generators |
| 1 x Cat, 800 kW | |
| Dredging machinery | |
| Dredge pumps | 2 x 1800 kW inboard freq. drive |
| 1 (/2) x 1350 kW UWP | |
| Jet pumps | 2 x 610 kW freq. drive |
| Deck equipment | |
| Fwd. crane | 12 t @ 15 m |
| Aft crane | 15 t @ 20 m |
| Accommodation | |
| Cabins | For 30 crew, all cabins en-suite |
| * DLL | Dredging Load Line |
