Tankers

General
Built:	2007
Class:	BV, oil tanker ESP, flash point >60C,
	Unrestricted Navigation
Trading Area:	Worldwide
Communication:	A1 + A2 + A3
Dimensions
Length oa:	62.4 m
Length bpp:	58.5 m
Beam:	12.0 m
Depth:	5.0 m
GT:	1,050
Loaded Draft:	3.76 m
Light ship:	690 mt
Deadweight:	1560 mt (Summer draft)
Cargo Capacity
HFO:	978 m3
Gas Oil:	380 m3
Slops:	32 m3
Total cargo capacity:	1,390 m3
Cargo Tanks	6 x abt 200 m3 , 2 x abt 114 m3
Cargo Equipment
Cargo pumps:	2 x NDX 800-L (200NB, 200 m3/hr)
	Max Loading Rate: 380 m3/h
	Max Discharge Rate: 250 m3/h
Tank coating:	Epicon T500
Boiler:	Maxithermal HRT-10
Ballast Pumps:	Desmi 2 x @ 100 m3/hr
Ballast Capacity:	735 m3
Tank Monitoring:	Whessoe/MMC
Machinery / Speed / Consumption
Main Engines:	2 x Cummins, NTA 855M 298 kW each
Aux Engines:	Kirloskar 1 x 30 kVA, 1 x 100 kVA
	and 1 x 150 kVA
Propeller:	2 x 4 blade
Bow Thruster:	1 HRP 242 Kw @ 242 rpm
Crane:	1 x SWL 10 Kn @ 6.5 x 19 m
Speed:	8 Knots
Bunker Capacity:	Main: 58.5 m3, Service: 2.5 m3, Bow thruster: 1.2 m3
FW Capacity:	24 m3

TYPE: DOUBLE HULL TANKER   OIL PRODUCTS

FLAG: COOK ISLANDS

CLASS: POLSKI REJESTR SRATKOW (CRUDE OIL TANKER (ESP II E))

BLT: 2013, RUSSIA, BY DON CASSENS SHIPBUILDERS, AKSAY NEXT SS: 05/2018;

LOA: 118,87 M; BREADTH: 13,24 M ;DEPTH: 5,5 M

GRT/NRT: 2748 / 1192 RT

DWT SEA/RIVER: 3955/2868 T

DRAFT SEA/RIVER: 4.3/3.6 M

CARGO TANKS CAPACITY: 4437 CUBM

CARGO PUMPS: 2 X 10ND6X1, 450 CUBM/H, P=5.8KG CARGO TANKS ARE COATED AND COILED

SPEED: 10 KN

MAIN ENGINES: 2 ?? 567 KW, 6NVD48A-2U, 335RPM

AUX: 3 X 100 KW, TBD226B-6CDI, 1500 RPM

EMERGENCY DG: 66 KW, TD226B-4CDI, 1500 RPM

1,970 DWT ON 4.4 MTR

L/B/D 77.4 / 10.60 / 5.3 M

GRT/NRT 1372/600 T

10 CARGO TANKS, 2247.98 CBM

EPOXY COATED

PUMPS 10 x 100 CBM/H DEEPWELL

STERN FITTED

SEGREGATION 5

HEATING SYSTEM – STEAM

HEATING COILS STAINLESS STEEL

M/E YANMAR 6N21A-EV, 960 KW AT 850 RPM

SERVICE SPEED 10.5 KNOTS AT 4.4T /DAY MDO

AUX 2 X 300 KW + 1 X 100 KW

BOW THRUSTER 200 KW + SHAFT GENERATOR 200 KW

DOUBLE HULL

VESSEL IS INSPECTABLE AT TURKISH PORT REGULARLY.

1,646 DWT ON 4.24M

BLT 2009 INDIA

CLASS BV OIL TANKER UNRESTRICTED NAV

SS/DD PASSED 2/2014 FLASH POINT>60 °C

LOA/B/D 63.60/12.02/5.80 M

GRT/NT 934/688

12 CARGO TANKS

2 SEGREGATIONS

COILED MILD STEEL – THERMAL OIL

CARGO TANKS NOT COATED – BALLAST TANKS COATED EPOXY

CARGO CAP (%98) 1,431 CBM + 68 CBM SLOPS

CARGO PUMPS 3X200 CBM SCREW TYPE

ME 2 X 373 KW CUMMINS

AUX 2 X 283 KW CUMMINS

ABT 10 KNOTS ON ABT 3TS

DOUBLE HULL

BOW TRUSTER 100 KW

TRADING ON OWNERS BUNKERING SERVICE WITHIN MED

1,500DWT ON 4.40M

BOILER, MON SHAFT,

10 CARGO TANKS EPOXY COATED CAP 1,430CBM

CARGO PUMPS 2 X 200 CBM – PUMP ROOM

2 SEGREGATIONS

ME CUMMINS KTA38-M2 895 KW

SERVICE SPEED ABT 11 KNOTS ON 2.5 TS DO

AUX 2 X 160 KW + 1 X 81 EMERG

SHAFT GEN 75 KW

DOUBLE HULL

VESSEL IS DESIGNED WITH A BOW TRUSTER ROOM.

Twin Engine/Propeller Bunkering Tanker

ABT 1800 DWT ON 4.2 M

LOA/LBP/B/D 73.72/70.60/10.40/4.80

GT/NT 1,173/505

10 CARGO TANKS+1 SLOP

CARGO CAP 1,889 CBM %100 (INCL SLOPS) – NOT COATED

CARGO PUMPS 2 X 220 CBM BORNEMAN – SCREW TYPE + 1 X 110 CBM BORNEMAN – SCREW TYPE

COILED – OIL THERMAL

ME 2 X 485 KW YANMAR 6AYM – FIXED PROPELLER

ABT 11.5 KNOTS

AUX 2 X 170 KW + 1 X 70 KW

BOW TRUSTER 90 KW

DB HULL
