180 ft x 60 ft 4-pm Spud barge (3 sisters)
Recent built (2014) spud barge equipped with 4 winched spuds and 4-point mooring. Location: Middle East Gulf. Enquire
| General | |
| Built | 2014 |
| Class | RINa, C ✠ Hull, unrestricted |
| Next SS due | May 2024 |
| Dimensions | |
| Length | 52.7 m (180 ft) |
| Beam | 18.3 m (60 ft) |
| Depth | 4.0 m (12 ft) |
| Draft (max/mt) | 3.2 m / 0.7 m |
| GT | 980 |
| Deck & Cargo capacity | |
| Deadweight | 2,400 t |
| Deck strength | 15 t/m2 |
| Deck area | 775 m2 |
| Deck equipment | |
| 4-pm winches | 4 x 10 t, 200 m wires |
| Anchors | 4 x 2 t |
| Spuds | 4 x 18 m x 0.8 m |
| Spud winches | 4 x 15 t |
| Machinery | |
| Generators | 2 x 80 kVA |
