24 september 2016300ft Heavy Lift Barge (3 sisters)
2011/2012, ABS class, unrestricted navigation. Deadweight abt. 8,400 t. SE Asia. For Charter only: Inquire
General | |
Built | 2011/2012 |
Class | ABS, + A1 Barge |
Dimensions | |
Length Overall | 91.5 m (300′) |
Breadth Moulded | 30.5 m (100′) |
Depth Moulded | 5.5 m (18′) |
GT | 3955 |
Deadweight | 8,435 tonne |
Deck Loading | 25 t/m2 |
Deck Equipment | |
Mooring Bollards | 6 x double bitts 10” N.B. bollards each side (recessed) |
Towing Brackets | 2 sets “SMIT” 80 t SWL – fitted forward & aft |
Winches | 2 x 5 tons hand winch – 1 unit for retrieving |
anchor & 1 unit for retrieving main tow gear | |
Anchor | 1 x 2,100kg Stockless Bower Anchor |
Fender | 3 rows steel fenders with 7 sets of wooden |
padded fenders fitted on each sides | |
Manhole | 1 x flushed manhole for each tank – “T” bar |
/single bolt locking type 500mm diameter | |
Navigation Lights | One set navigation lights |
Pilot Ladders | Flush (pigeon holes) type installed each side |
Others | Barge is all welded steel construction with flush |
main deck, fitted with twin skegs stern. | |
Transverse Bulkhead | Eight (8) transverse bulkheads (watertight) |
Longitudinal Bulkhead | Three (3) longitudinal bulkheads (watertight) |
No. of compartments | Thirty-two (36) compartments |
