450 m³ Self-propelled Split Hopper Barge NB
IACS class, l x b x d (m): 48.0 x 9.0 x 3.4 Deadweight 760 t. Propulsion: 2 x 220 kW rudder propeller. Location: EU. Inquire
| General | |
| Built | 10-12 months after date of order |
| IACS Class | e.g. GL, +100 A 5 RSA(20) Split Hopper Barge |
| Dimensions | |
| Length oa | 48.0 m |
| Beam | 9.0 m |
| Depth mld | 3.4 m |
| Draft (LL exem.) | 2.9 m |
| Hopper volume | 450 m3 |
| Deadweight (LL exem.) | 760 t |
| Machinery | |
| Propulsion | 2 x 220 kW rudder propeller |
| Split cylinders | 2 x, operated by hydraulic power pack |
| Overflow | Manually adjustable |
| Safety and firefighting equipment | |
| As per flag state requirements | |
