60 tbp Z-drive Tugs (2 sisters)
2005 solid design and built 60 tbp Z-drive tugs, main engines 2 x Cat 3516 driving FP Schottels. FiFi equipment. accommodation for 10 crew. location. Far East. Enquire
| General | |
| Built | 2005 |
| Class | LR, + 100 A1 LR, Tug, + LMC, UMS |
| Dimensions | |
| Length | 27.4 m |
| Beam | 11.5 m |
| Depth | 5.0 m |
| Draft | 5.2 m |
| GRT | 328 |
| Performance | |
| Speed | 12.5 knots |
| Bollard pull | 60.0 t |
| Machinery | |
| Main engines | 2 x Cat 3516B, 1865 kW each |
| Propulsion | 2 x Schottel, SRP 1215FP |
| Generators | 2 x 84 kW or 2 x 112 kW |
| Deck equipment | |
| Escort winch | 150 t hold, |
| 20-10 t @ 10-20 m/min pull | |
| Crane | 1.5 t @ 6 m |
| Fire Fighting | |
| Pump | 1 x 1,400 m³/hr @ 125 m head |
| Monitors | 2 x foam/water 600 m³/h each |
| Water curtain | Yes |
| Tank capacities | |
| Fuel | 110 m³ |
| Fresh water | 23 m³ |
| Dispersant | 3.0 m³ |
| Foam | 3.0 m³ |
| Navigation and Communication | |
| Radar, SSB, VHF, Echo sounder, Inmarsat-C, | |
| Navtex, EPIRB, Auto pilot, AIS | |
| Accommodation | |
| Cabins | 2 x 1-berth, 1 x 2-berth, 2 x 3-berth |
| Other | Galley, mess room, sanitary facilities |
| air-conditioned | |
