62 tbp ASD AHT FiFi-1 (2 sisters)
AHT, Terminal, Escort & FiFi-1
2001, BV Class, 2 x 1.840 kW each, l x w x d (m): 35.00 x 11.50 x 4.50, bollard pull ahead/astern: 62/57 tons, aft winch waterfall conf 75/145 ton, fwd winch single drum 35/100 ton. FiFi-1, 2 x 1.200 m3/h, WAF. Price: Inquire
| GENERAL | ||
| Bureau Veritas 1 + HULL, + MACH, Tug – Fire fighting ship 1, Unrestricted navigation | ||
| Built | 2001 | |
| DIMENSION | ||
| Length over all | 35.00 | m |
| Beam over all | 11.50 | m |
| Maximum draught | 4.50 | m |
| GT | 496 | |
| MACHINERY/PROPULSION | ||
| Main engines | 2 x Yanmar 6N280 | |
| Total power | 3,680 | kW |
| Propulsion | 2 x controllable pitch ASD propeller | |
| Bow thruster | 1 x 110 | kw |
| PERFORMANCE | ||
| Bollard pull (ahead) | 62 | tons |
| Bollard pull (astern) | 57 | tons |
| Speed ahead (maximum) | 14 | knots |
| Speed (economic) | 11 | knots |
| TANK CAPACITY | ||
| Fuel oil | 245 | m³ |
| Potable water | 80 | m³ |
| Foam | 14 | m³ |
| ACCOMMODATION | ||
| Accommodation , air-conditioned, for | 14 | persons |
| DECK AREA | ||
| Deck area (aft) | 120 | m² |
| DECK EQUIPMENT – FORE | ||
| Fore winch | Hydraulic | |
| Single drum – 100 T. brake load | ||
| Line pull 35 T. @ 10 m/min. on 1st layer | ||
| DECK EQUIPMENT – AFT | ||
| Aft winch | Hydraulic | |
| Waterfall (2 drums) – 145 T. brake load | ||
| Upper drum – Line pull 75 T. @ 5 m/min. on 1st layer | ||
| Lower drum – Line pull 75 T. @ 5 m/min. on 1st layer | ||
| Stern roller | 1.4 m. x 4.8 m., 130 SWL | |
| Tugger winch | 1 x 5 tons.@ 15 m/min. | |
| Towing pins | x T. SWL | |
| OTHER EQUIPMENT | ||
| Capacity fire-fighting monitors | 2 x 1,200 m³/hr | |
| Crane | 1.54 tons SWL. @ 5.2 m. outreach | |
