73 tbp ASD AHT (2 sisters)
2 september 2016
70 tbp ASD Escort Tug (2 sisters)
2 september 2016
45 tbp ASD Escort Tug (2 sisters)
Escort, Harbour, Coastal, Terminal & FiFi
2008, BV Coastal, 2 x Niigata 6L25HX, 1.200 kW each, l x w x d (m): 28.00 x 9.80 x 4.00, bollard pull ahead/astern: 45/40 tons, forward/aft single drum 100 ton brake load, FiFi 2 x 600 m3/h, ME Gulf. Price: Inquire
| General | |
| Built | 2009 |
| Class | Bureau Veritas 1, ✠ Hull, ✠ Mach, |
| Tug, Coastal Area | |
| Performance | |
| Speed | 12 knots ahead / 9 knots astern |
| Bollard pull | 45 t ahead / 40 t astern |
| Dimensions | |
| Length | 28.0 m |
| Width | 9.8 m |
| Depth | 4.8 m |
| Draft (max.) | 4.0 m |
| GRT | 329 |
| Machinery | |
| Main engines | 2 x Niigata 6L25HX, 1323 kW each |
| Propulsion | 2 x FP ASD |
| Generators | 2 x 122 kW |
| Tank capacities | |
| Fuel oil | 143 m3 |
| Potable Water | 30 m3 |
| Foam | 5 m3 |
| Deck equipment | |
| Escort winch | Hydraulic, Single drum – 100 t hold, |
| Pull 10 t @ 15 m/min on 1st layer | |
| Towing winch | Hydraulic, Single drum – 100 t hold, |
| Pull 40 t @ 7 m/min on 1st layer | |
| Towing hook | Disc type, pneumatic, 45 t SWL |
| Fi-Fi pump | 1 x M/E driven |
| Fi-Fi monitors | 2 x 600 m3/hr |
| Navigation & Communication | |
| Magnetic compass | Daico Keiki Seisakusho SR-150PK |
| Echo sounder | Marinetek Seamax Colour |
| VHF | lcom M59 |
| Radar | Furuno 1721 |
| GPS | Furuno GP-31 |
| Accommodation | |
| Cabins | 10 persons (air-conditioned) |
