100+ tbp FiFi-1 AHTs (2 sisters)
2011, BV class, 100+ tbp AHT with limited supply capability. L x B x D (m): 52.0 x 15.0 x 6.5. Draft: 5.7m. location ME. Enquire
| General | |
| Built | 2011 |
| Class | BV, I ✠ Hull ✠ Mach, Tug; Fire Fighting Ship 1 – |
| Water Spraying; Special Services – Anchor Handling, | |
| Unrestricted navigation | |
| Dimensions | |
| Length oa | 52.0 m |
| Beam | 15.0 m |
| Depth Mld | 6.5 m |
| Draft (max) | 5.7 m |
| Freeboard (SLL) | 0.80 m |
| GRT | 1498 |
| Deck particulars | |
| Clear Deck Area | 240 m² |
| Deck Carrying Load | 200 t |
| Deck Strength | 5.0 t/m² |
| Performance | |
| Bollard Pull | 104 t |
| Max. speed | 4.5 Knots @ 15-16t / 24 hrs |
| Eco. speed | 12 Knots @ 13 t / 24 hrs |
| Deadweight | 1025 t |
| Machinery | |
| Main Engines | 2 x General Electric 16V228, 3050 kW each |
| Auxiliary Engines | 3 x Cummins KTA19, 380 kW each |
| Emergency Generator | 1 x Cummins, 175 kW |
| Bow Thruster | Kamome CPP Electric Driven, 6.6 t |
| Stern Thruster | Kamome CPP Elec Driven, 4.9 t |
| Propellers | 2 x Kamome CPP in Fixed Nozzles |
| Steering Gear System | 2 x Electro-Hydraulic |
| Rudder | 2 x Heel Pintle |
| Deck equipment | |
| Fwd winch | 1 x Single drum |
| Aft winch | Double drum, pull 250 t, brake 400 t waterfall |
| Pull, brake | 250 t @ 6 m/min, 400 t @ 1st Layer |
| Drum Capacity | 2 x 1000 m x 60 mm |
| Spare Drum Capacity | 1000 m x 71 mm, 10 t x 20 m/min |
| Towing Pin | SWL 300 t |
| Shark Jaw | SWL 350 t |
| Stern Roller | SWL 400 t, 6.0 m x 1.5 m |
| Tugger Winch | 2 x 10 t @ 5 m/min |
| Capstan | 2 x 5 t @ 5 m/min |
| Crane | 5 t @ 15 m reach |
| Tank-, Pump capacities | |
| Fuel Oil | 595m³, 100 m³/hr |
| Fresh Water | 267 m³, 100 m³/hr |
| Drill Water | 122 m³, 100 m³/hr |
| Bilge | 5.5 m³, 70 m³/hr |
| Ballast Water | 125 m³ |
| FiFi and Lifesaving equipment | |
| Class | FiFi-1 |
| Monitors | 2 x Fi-Fi Monitor, 1200 m³/hr, 120 m throw |
| Fi-Fi Pump | 2 x Fi-Fi Pumps, 1650 m³/hr |
| Life Rafts | 2 x 10, 2 x 20 men |
| Rescue Boat c/w Davit | 1 x 6 Men, 20 HP of outboard |
| Accommodation | |
| Cabins | 6 x 1-berth, 10 x 2-berths |
| Total | 26 |
