70 pax Fast Supply Crewboat / Utility Vessel
12 september 2016
75 Pax DP-1 Fast Supply Crewboat / Utility Vessel
12 september 2016
72 pax Fast Supply Crewboat / Utility Vessel
Mono hull, fixed props
ABS. L x b x d (m): 40.00 x 7.60 x 3.60. Draft 1.95 m. Speed: 25 knots, 90 m2 deck area, propulsion: 3 x 1,660 bhp, fixed props. 72 pax + 10 crew. Price: Inquire
| GENERAL | |
| Year Built | 2015 |
| Classification | Bureau Veritas, |
| I + Hull + Mach Crew Boat, Sea area 2 (max. sig. wave height 2.5m) | |
| MEASUREMENT | |
| Length Overall | 40.00 m |
| Breadth Moulded | 7.60 m |
| Depth Moulded | 3.60 m |
| Design Draft | 1.95 m |
| TONNAGE | |
| Deadweight | |
| GT / NT | 258 / 77 |
| MACHINERY | |
| Main Engine | Yanmar 12AYM-WET, 1,660 bhp each |
| Gearbox | Twin Disc MGX6848SC, ratio 2.47:1 |
| Propeller | 3 x FPP |
| Bow Thruster | 1 x 1.5 Ton |
| Genset | Sabre Perkins 6TG2AM |
| CARGO DECK | |
| Deck Area | 90 m² |
| Deck Strength | 1.5 Ton / m² |
| Deck Cargo Capacity | 45 Ton |
| TANK CAPACITY | |
| Fuel Oil | 76.5 m³ |
| Fresh Water | 30.0 m³ |
| DISCHARGE CAPACITY | |
| Fuel Oil | 14 m³/hr @ 50 m head |
| Fresh Water | 30 m³/hr @ 54 m head |
| FUEL CONSUMPTION | |
| Cruise | 255lt/hr @ 85% MCR |
| Max speed (25 knots) | 305lt/hr @ 100% MCR |
| DECK EQUIPMENT | |
| Anchor Windlass | 8.33kn @ 12m/min |
| Anchor Chain | 14mm x 27.5m Grade 2 |
| Anchor | 140kg |
| Wire Rope | 16mm x 110m Galv |
| NAVIGATION AND COMMUNICATION EQUIPMENT | |
| MF/HF DSC | 1 x Furuno FS-1575 |
| VHF DSC | 1 x Furuno FM-8900 |
| GMDSS VHF | 3 x Samyung STV-160 |
| NAVTEX | 1 x Furuno NX-700B |
| EPIRB | 1 x Samyung SEP-406 |
| SART | 1 x Samyung SAR-9 |
| Radar X- Band | 1 x Furuno FAR-2117 |
| Radar | 1 x Furuno-1935 |
| Echo sounder | 1 x JMC F-2000 |
| GPS Navigator | 1 x Furuno GP-32/150 |
| AIS | 1 x Haiyang HIS-70A |
| Wind speed | 1 x Clipper wind |
| Satelite compass | 1 x Furuno SC-50 |
| Autopilot | 1 x Navpilot 700 |
| BNWAS | 1 x BWAS2000 |
| Broadband | 1 x Sailor 250 |
| PA system | Vingtor CTB-20 |
| MISCELLANEOUS | |
| Oily water Separator | 0.5 m³/hr |
| Sewage Treatment | 15 Men |
| ACCOMODATION | |
| Cabins | 5 x 2 men cabin |
| 1 x 1 men cabin | |
| 1 x prayer room | |
| 1 x VIP/First Aid Room | |
| Passengers | 72 |
