31 TBP Damen Stantug 3008 FiFi
Coastal towage, barge handling & towage, general assistance tug
1998, BV unrestricted, versatile, solid built. 2 x Cat 3512, 31 ton bollard pull, FiFi 2 x 180m3/h. accommodation for 12 crew. West Africa. Price: Inquire
| General | ||
| Class | BV, 1 + HULL, MACH, Tug, Unrestricted Navigation | |
| Built | 1998 | |
| Dimensions | ||
| Length over all | 30,30 | m |
| Width | 8,42 | m |
| Draft (max.) | 3,29 | m |
| GT | 212 | |
| Machinery & propulsion | ||
| Main engine | 2 | Caterpillar 3512-01-TA/A |
| Total power | 1.910 | kW |
| Propulsion | 2 | fixed pitch |
| Bow thruster | 112 | kW |
| Performance | ||
| Speed ahead (max.) | 13 | knots |
| Speed (eco.) | 11 | knots |
| Bollard pull (ahead) | 31 | ton |
| Tank capacity | ||
| Fuel oil | 62 | m3 |
| Potable water | 42 | m3 |
| Foam | 5 | m3 |
| Accommodation | ||
| Crew | 12 | persons |
| Navigation & communication | ||
| Magnetic compass | Kelvin Hughes Observator | |
| Echo sounder | Furuno FE-700 | |
| VHF | Sailor RT2048 | |
| Radar | Furuno FR- 8050 | |
| GPS | Trimble | |
| Deck equipment | ||
| Towing hook | 45 | ton, Mampaey, disc type |
| Aft winch | Hydraulic, single drum | |
| Brake load | 100 | ton |
| Line pull | 10 | ton |
| Line speed | 10 | m / min (3rd layer) |
| Other equipment | ||
| Fire-fighting monitors | 2 | |
| Capacity each monitor | 180 | m3/hr |
