54 tbp Shallow Draft FiFi-1 AHT
5 september 2016
Shoalbuster 2609 (2 sisters)
5 september 2016
39 tbp shallow draft AHT
Towing, Anchor Handling, Dredge Support and Ploughing 2013, BV. l x w x d (m): 27.0 x 9.1 x 3.5, max. draft 2.65 m. 2 x Cat 3512, 2,240 kW, 39 tbp. knuckle boom crane: 5,2 ton @ 18 m. Northsea. Inquire
| General | |
| Built | 2013 |
| Class | BV, I ✠ Hull • Mach, Tug, Unrestricted |
| Navigation, • AUT-UMS (SS) | |
| Dimensions | |
| Length | 27.0 m |
| Beam | 9.10 m |
| Depth | 3.6 m |
| Draft Aft | 2.6 m |
| GRT | 145 t |
| Performance | |
| Speed | 12 knots |
| Bollard Pull | 38.8 t |
| Deck equipment | |
| Deck Crane | 5.3 t at 18 m reach |
| AH / towing winch | Waterfall configuration |
| 120 t hold, 850 m x 40 mm wire | |
| 120 t hold, 650 m x 40 mm wire | |
| Towing Pins | Double |
| Tugger Winch | 12 t @ 4.5 m/min |
| Stern Roller | 50 t @ 45 degree |
| Moon Pool | |
| A-frame | (optional) |
| Machinery | |
| Main Engines | 2 x Cat. 3512, 2250 kW each |
| Propulsion | 2 x FPP in nozzles |
| Bow thruster | 1 x 150 kW, Hydraulic |
| Generators | 2 x Cat. C4.4, 55 KW ea |
| Hydr. power pack | 1 x Cat. C9, 269 kW |
| Tank Capacity | |
| Fuel | 125 m³ |
| Fresh water | 30 m³ |
| Accommodation | |
| Cabins | 3 x 1-berth, 2 x 2-berth |
| Other | galley/ mess & sanitary |
| AC & Heating | |
