62 tbp FiFi-1 Escort ASD tug
Withdrawn by owners. 2002, Solid built. Well maintained Damen 3211. FiFi-1 Escort ASD tug. Recently renewed class. 2 x Wartsila 6L26, 1830 kW each. Location: Caribbean. Enquire
| General | |
| Built | 2002 |
| Class | LR, ✠ 100A1 escort tug, fire fighting Ship 1 |
| (2400 cubic m/hr) with water spray, | |
| occasional oil recovery duties, ✠ LMC UMS | |
| Dimensions | |
| Length oa | 32.5 m |
| Beam | 11.2 m |
| Depth | 5.0 m |
| Draft | 4.1 m |
| GRT | 398 |
| Performance | |
| Speed | 13.6 Kn |
| Bollard pull | 62 t ahead, 55 t astern |
| Fuel consumption | 670 ltr/h at 100% load |
| Machinery | |
| Main engine | 2 x Wartsila 6L26, 1830 kW each |
| Propulsion | 2 x Schottel SRP 1515 CP |
| Bow thruster | 1 x Schottel, 200 kW |
| Generators | 2 x Deutz BF 6M, 115 kVA each |
| Port generator | 1 x 30 kW – 20 kVA |
| Deck equipment | |
| Escort winch | Double drum – brake 150, pull 82 t @ 6 m/min |
| Aft winch | Single drum – brake 150 t, pull 60 t @ 8 m/min. |
| Towing hook | Mampaey, disc type, 70 t SWL |
| Stern roller | yes |
| Deck crane | Knuckle boom |
| Fire fighting | |
| Class | FiFi-1 |
| Pumps | PTO driven |
| Monitors | 2 x 1200 m³/hr |
| Water spray | yes |
| Tank capacities | |
| Fuel oil | 160 m3 |
| Fresh water | 70 m3 |
| Ballast | 35 m3 |
| Navigation and Communication | |
| GMDSS A1 + A2 + A3 | |
| 2 x radar, magnetic compass, gyro compass, autopilot, GPS, VHF – | |
| GMDSS, Navtex, Inmarsat C, EPIRB | |
| Accommodation | |
| Cabins | 4 x 1-berth, 2 x 2-berth |
| Air-conditioned | |
